6 kW – DC Power System Subrack
XXX
Spesification
| General | |
| Parameter | Description |
| Maximum Capacity | 3000 W |
| DC Input Data | |
| Parameter | Description |
| Input Voltage (Nominal) | 58 – 150 VDC, Rated 100 VDC |
| MPPT Voltage Range | 58 – 120 VDC |
| Max. Input Current | 52 A |
| MPPT Accuracy | ≥ 0.99 @load ≥ 400W |
| DC Output Data | |
| Parameter | Description |
| Output Voltage Range | 42 to 58 VDC (Rated 53.5V) |
| Max Output Current | 41.7 A |
| Peak Efficiency | >97 % |
| Dimension | |
| Parameter | Description |
| Dimension (H x W x D) | 41.5 x 106.4 x 291 mm |
| Control and Monitor | |
| Parameter | Description |
| Communication Protocol | CAN |
| LED | Green-normal, yellow-alarm, red-fault |
| Certification and Safety | |
| Parameter | Description |
| Certifications | Designed According to IEC/EN62109-1, IEC/EN 62368-1, standards |
| Electromagnetic Compability | EN 55032 RE Class A |
Performance Curve
