Spesification
| General | |
| Parameter | Description |
| Maximum Capacity | 4350 W |
| AC Input Data | |
| Parameter | Description |
| Input Voltage (Nominal) | 110 VAC / 220 VAC |
| Operating Voltage | 85-290 VAC |
| Max. Input Current | 26 A |
| Input Frequency | 45 Hz – 65 Hz |
| Power Factor | ≥ 0.99 (220 VAC @20 % to 100% load) |
| DC Output Data | |
| Parameter | Description |
| Output Voltage Range | 42 to 58 VDC (Rated 53.5V) |
| Max Output Current | 81.3 A |
| Peak Efficiency | >97 % |
| THD | < 3% @ ≥50% load (220VAC) |
| Dimension | |
| Parameter | Description |
| Dimension (H x W x D) | 41.5 x 106.4 x 291 mm |
| Control and Monitor | |
| Parameter | Description |
| Communication Protocol | CAN |
| LED | Green-normal, yellow-alarm, red-fault |
| Certification and Safety | |
| Parameter | Description |
| Certifications | CE CUL CB UL 62368-1, EN 62368-1, IEC 62368-1 |
| Electromagnetic Compability | EN 55032 class B, EN 55035, IEC 61000-3-11, IEC 61000-3-12 |
